Shaft seal set | Sachs 506

Motorex Automatic Motor Oil (ATF) 450 ml

Manufacturer: Motorex · Contents [ml]: 450 ml · Area of application: Gearbox lubrication with clutch · Gearbox type: Automatic machine · Temperature resistance (min.): -45 - 200 °C · Pony OEM number: A2080 · Sachs OEM no.: 0263 014 002

swiing® revival screw set Motor E50 Inox | Puch Maxi

Surface: stainless · Manufacturer: swiing® revival parts · Material: Chrome steel (known as Nirosta®)

DMP 45 mm cylinder kit incl. diaphragm | Puch

Manufacturer: DMP · Material: Aluminum · Camouflaged: No · Surface: sandblasted · Displacement: 70 ccm · Crankshaft stroke: 43 mm · Nominal diameter: 45 mm · Hole pattern [mm]: 44 x 44 · Number of fixing points: 4 pcs · Ø piston pin (B): 12 mm · Hole spacing outlet: 42 mm · Thread outlet: M6x1 (standard thread) · Area of application: Tuning

Polini jet set (120 - 138) main jets long version CP, Keihin, Koso, PWK

Manufacturer: Polini · Component group Carburetor: Spraying · Material: Brass · Carburetor type: CP · Carburetor type: Coso · Carburetor type: Keihin · Carburetor type: PWK · Quantity: 10 pcs · Nozzle type: Main nozzle · Nozzle size: 120 · Nozzle size: 122 · Nozzle size: 124 · Nozzle size: 126 · Nozzle size: 128 · Nozzle size: 130 · Nozzle size: 132 · Nozzle size: 134 · Nozzle size: 136 · Nozzle size: 138 · Drive: External hexagon

Loctite 510 sealant 50 ml

Manufacturer: Loctite · Material: Silicone · Contents [ml]: 50 ml · Area of application: Chemistry · Color: pink · Hazard warning: Causes serious eye irritation · Hazard warning: May cause allergic skin reactions · Hazard warning: May irritate the respiratory tract · Signal word: Attention · Hazard pictogram: GHS07 - Caution dangerous · Temperature resistance (min.): -55 - 250 °C · Gap dimension (max.): 0.25 mm

66HEROES Tank cap "Puch" bayonet 40 mm black

Surface: anodized · Manufacturer: 66HEROES · Material: Aluminum · Fuel filler cap: Bayonet 40 mm · Lockable: No · Color: black · Vented: Yes

Rito crankshaft full cheeks with mounted bearings | Puch E50

Manufacturer: Rito · Area of application: High End · Material: Steel · Cheek type: Full cheeks · Thread type: MF10x1 (fine pitch thread) · Crankshaft stroke: 43 mm · Ø piston pin (B): 12 mm · Connecting rod length center-center: 90 mm · Total length of crankpin on clutch side: 74 mm · Total length crankpin ignition side: 66 mm · Ø crank webs: 69.9 mm · Ø Connecting rod eye: 15 mm · Ø Bearing seat (clutch side): 17 mm · Ø Bearing seat (ignition side): 17 mm · Dimension needle bearing: 12 / 15 x 14.2 (axe 12) · Wide crank webs: 34 mm · Length 1st paragraph: 9 mm · Thread length: 10 mm · Length 2nd paragraph: 14.5 mm · Length 3rd paragraph: 25 mm · Ø 1st step (on the coupling side): 22 mm · Ø 2nd shoulder (on the clutch side): 17 mm · Ø 3rd step (on the clutch side): 15 mm · Length of shoulder (ignition side): 26.6 mm

Polini CP 21 mm carburetor & air filter (cable choke)

Nominal diameter: 21 mm · Manufacturer: Polini · Component group Carburetor: Carburetor complete · Material: Aluminum · Carburetor type: CP · Area of application: Tuning · Choke control: Cable choke · Nozzle thread: M5x0.8 (standard thread) · Mounting type: Plug connection · Ø fuel hose connection: 6 mm · Ø without reducing sleeve: 25 mm · Nozzle size: 100 · Ø Internal connection: 24 mm · Ø Air filter connection: 46 mm · Mixed oil connection: Yes · Vacuum connection: Yes · Size of secondary nozzle: 40

Clutch reinforced | Puch E50

Material: Composite materials · Material: Steel · Recording type: Cone mounting · Ø outside: 92 mm · Number of jaws: 3 pcs · Ø inside: 12 mm · Ø inside: 14.3 mm · Number of springs: 12 pcs · Thickness: 22.15 mm · Area of application: Road use · Area of application: Tuning
