Spare parts catalog | Puch X30 NS / NL (CH)

Karcoma fuel tap M12x1 vertical (with union nut) 2 connections

Manufacturer: Karcoma · Possible lever positions: open / closed / reserve · Material lever: Metal · Filter type: Plastic net · Ø fuel hose connection: 6 mm · Thread type: MF12x1 (fine pitch thread) · Mounting type: Union nut · Installation direction: vertical / vertical · Outlet direction: any · Spare tube shape: straight · Reserve level: 50 mm

swiing® revival cable guide mudguard black | Puch

Manufacturer: swiing® revival parts · Material: Plastic · Color: black · Total length: 74 mm · Mounting type: Plug connection · Number of fixing points: 2 pcs · Height: 12.5 mm · Hole spacing: 63 mm

swiing® revival air filter screen Ø 52 mm original

Manufacturer: swiing® revival parts · Camouflaged: No · Material: Steel · Surface: galvanized (blue) · Area of application: Standard · Color: silver · Ø outside: 52 mm · Height: 10 mm

Repair instructions | Puch X30 A / N

Material: Paper · Number of pages: 40 pcs · Language: German

swiing® revival 17" front fender Inox | Puch X30 NS, NL, NG-2AH, N-2AH, Sprinter

Manufacturer: swiing® revival parts · Material: Chrome steel (colloquially known as stainless steel) · Surface: polished · Color: Chrome · Folding the ends: closed folded · Shape of the mudguard: partly round · Total length over ends: 565 mm · Scope: 700 mm · Wide mudguard profile: 80 mm · Height of mudguard profile: 40 mm · Mounting type: Nuts & bolts · Total height from support surface to top edge: 185 mm · Wheel size: 17 "

swiing® revival 17" rear fender Inox | Puch X30 NS, NL, NG-2AH, N-2AH, Sprinter

Manufacturer: swiing® revival parts · Material: Chrome steel (colloquially known as stainless steel) · Surface: polished · Color: Chrome · Folding the ends: closed folded · Folding the ends: not folded · Shape of the mudguard: partly round · Total length over ends: 635 mm · Scope: 1005 mm · Wide mudguard profile: 80 mm · Height of mudguard profile: 40 mm · Mounting type: Screws · Total height from support surface to top edge: 320 mm · Wheel size: 17 "

Repair instructions | Puch X30 NS/NL

Material: Paper · DIN format: A4 · Number of pages: 29 pcs · Language: German

GPO front mudguard strut 17" chrome

Total length: 305 mm · Manufacturer: GPO · Material: Steel · Outer width: 160 mm · Surface: chrome-plated · Color: Chrome · Distance mudguard - center hole: 300 mm · Mounting type: Nuts & bolts · Number of fixing points: 4 pcs · Ø mounting hole: 12.5 mm · Wheel size: 17 "

Operating instructions | Puch X30 Sport NS/NL

Material: Paper · DIN format: A5 · Number of pages: 48 pcs · Language: German
