Seat bench with substructure black | Piaggio SI FL

Seat black | Piaggio SI FL

Manufacturer: Made in Italy · Material: Imitation leather · Color: black · Spring-loaded: No · Lettering: No · Total length: 430 mm · Width: 120 mm · Width: 150 mm · Width: 240 mm · Height: 80 mm · Number of fixing points: 4 pcs · Hole pattern [mm]: 66 x 53

Seat black | Piaggio SI

Manufacturer: Made in Italy · Material: Imitation leather · Color: black · Spring-loaded: No · Lettering: No · Total length: 430 mm · Width: 130 mm · Width: 180 mm · Height: 100 mm · Number of fixing points: 6 pcs · Hole pattern [mm]: 25

Magura gas cable clamp / deco cable clamp Ø 5 x 6 mm

Manufacturer: Magura · Material: Brass · Material: Steel · Surface: nickel-plated · Total length: 6 mm · Ø Cable bushing: 1.6 mm · Drive: Slot · Screw head: Lens head · Thread type: M4x0.7 (standard thread) · Ø outside: 5 mm · Thread length: 4 mm · Number of components: 2 pcs

Lusito throttle twist grip short throttle black / orange

Total length: 180 mm · Manufacturer: Lusito · Housing material: Aluminum · Material: Rubber · Surface: powder-coated · Color: black · Color: orange · Number of components: 2 pcs · Ø inside: 22 mm

EFFE breaker without cable | Piaggio Ciao, SI, Bravo, Boxer

Manufacturer: EFFE · Area of application: Original · Area of application: Standard · Material: Steel · Ø mounting hole: 4.5 mm · Cable available: No · Ø axle: 5 mm · Number of fixing points: 1 pcs · Piaggio OEM number: 103133

Jasil crankshaft "original" 10 mm KoBo | Piaggio Ciao, SI, Bravo, Boxer

Manufacturer: Jasil · Cheek type: standard · Crankshaft stroke: 43 mm · Ø coupling pin / vario pin: 12 mm · Connecting rod length center-center: 87 mm · Total length crankpin ignition side: 91.5 mm · Ø piston pin (B): 10 mm · Ø Connecting rod eye: 13 mm · Ø Bearing seat (clutch side): 15 mm · Ø Bearing seat (ignition side): 15 mm · Thread type: M8x1.25 (standard thread) · Dimension needle bearing: 10 / 13 x 14.2 mm (axe 10) · Wide crank webs: 33 mm · Length 1st paragraph: 21.5 mm · Length 2nd paragraph: 43.5 mm · Length 3rd paragraph: 64 mm · Number of gears: 1 pcs · Area of application: Standard

Spring washer flywheel | Piaggio Ciao, SI, Bravo, Boxer

Spring design: Special spring · Material thickness: 0.2 mm · Ø inside: 14.7 mm · Ø outside: 20.5 mm · Manufacturer: Made in Italy · Material: Spring steel · Area of application: Standard

Athena 38.4 mm cylinder kit without head 10 mm KoBo | Piaggio Ciao, SI, Bravo, Boxer

Nominal diameter: 38.4 mm · Manufacturer: Athena · Material: Aluminum · Surface: sandblasted · Displacement: 50 ccm · Crankshaft stroke: 43 mm · Ø cylinder neck: 45.7 mm · Ø Outlet outside: 22.5 mm · Ø outlet inside: 18 mm · Ø piston pin (B): 10 mm · Outlet type: clamped · Number of fixing points: 3 pcs · Hole pattern [mm]: 35 x 55 · Decompressor: Yes · Camouflaged: No · Area of application: Tuning

swiing® revival condenser with cable | Piaggio Ciao, SI, Bravo, Boxer

Manufacturer: swiing® revival parts · Capacity: 0.28 µF · Total height: 31 mm · Ø outside: 18 mm · Height: 26 mm · Mounting type: Tab for screwing · Connection type: Cable for screwing · Ø mounting hole: 4.4 mm · Area of application: Original · Area of application: Standard · Piaggio OEM number: 102939

Large flywheel rubber (from 1975) original | Piaggio Ciao, SI, Bravo, Boxer

Manufacturer: Piaggio · Material: Rubber · Color: black · Width: 24 mm · Width: 27 mm · Total length: 42 mm · Total length: 47 mm · Piaggio OEM number: 166554

Rubber grommet ignition cable engine (electronic ignition) | Piaggio Ciao, SI, Bravo, Boxer

Material: Rubber · Color: black · Ø inside: 6 mm · Ø outside: 10.5 mm · Total length: 33 mm · Ø Cable bushing: 6 mm · Ø mounting hole: 12.5 mm · Ø Bundle: 15 mm · Ø Bundle: 16.5 mm · Waistband height: 5 mm · Total height: 27 mm · Material thickness: 1.7 mm · Piaggio OEM number: 000/073943
