Gurtner O-ring fuel connection carburetor AR2 | MBK, Motobécane (AV7)

Gurtner carburetor AR 2/10 original | MBK / Motobécane 4/85 (AV71)

Total length: 50 mm · Manufacturer: Gurtner · Material: Aluminum · Component group Carburetor: Carburetor complete · Nominal diameter: 10 mm · Choke control: Cable choke · Width: 80 mm · Height: 101 mm · Ø Internal connection: 16 mm · Ø without reducing sleeve: 19 mm · Ø Inside entrance: 10 mm · Ø Output inside: 10 mm · Area of application: Original · Area of application: Standard · Ø fuel hose connection: 6 mm · Nozzle size: 52 · Mounting type: Plug connection clamped

Standing throttle screw Gurtner carburetor D12G

Total length: 21 mm · Material: Steel · Component group Carburetor: Adjusting screws, float, etc. · Surface: galvanized (blue) · Carburetor type: Gurtner DG · Thread type: M5x0.8 (standard thread)

Gurtner carburetor float AR | MBK, Motobécane (AV10, AV7)

Ø outside: 23.7 mm · Manufacturer: Gurtner · Material: Plastic · Component group Carburetor: Adjusting screws, float, etc. · Carburetor type: Gurtner AR · Height: 19.8 mm · Height: 41.1 mm

Gurtner fuel filter carburetor AR2 / DG | Peugeot 102, 103, MBK, Motobécane

Ø outside: 8 mm · Total length: 29 mm · Manufacturer: Gurtner · Material: Plastic · Component group Carburetor: Adjusting screws, float, etc. · Color: white · Carburetor type: Gurtner AR · Carburetor type: Gurtner DG

Gurtner spring throttle slide carburetor AR | MBK, Motobécane (AV7, AV10)

Spring design: Pressure spring · Ø wire: 0.8 mm · Total length: 33.5 mm · Manufacturer: Gurtner · Area of application: Original · Material: Spring steel · Area of application: Standard · Ø inside: 8 mm · Carburetor type: Gurtner AR · Number of components: 1 pcs · Ø outside: 9.5 mm

ESJOT sprocket 40 teeth 4-hole coaster black

Chain pitch: 1/2" x 3/16" · Chain type: 415H · Ø inside: 94 mm · Manufacturer: ESJOT · Material: Steel · Surface: powder-coated · Color: black · Thickness: 4.5 mm · Number of teeth: 40 pcs · Ø bolt circle: 105.5 mm · Hole spacing: 74 mm · Ø mounting hole: 6.4 mm · Number of fixing points: 4 pcs

GPO 45 mm cylinder kit (large ribs) | Puch

Nominal diameter: 45 mm · Manufacturer: GPO · Material: Aluminum · Surface: sandblasted · Displacement: 70 ccm · Crankshaft stroke: 43 mm · Ø cylinder neck: 47.8 mm · Ø outlet inside: 24.6 mm · Inlet window: 21.8 x 14.6 · Thread inlet: M6x1 (standard thread) · Hole spacing inlet: 38 mm · Ø piston pin (B): 12 mm · Outlet type: straight · Hole spacing outlet: 42 mm · Thread outlet: M6x1 (standard thread) · Number of fixing points: 4 pcs · Hole pattern [mm]: 44 x 44 · Decompressor: No · Camouflaged: No · Area of application: Tuning

GPO sprocket 45 teeth black | Puch Maxi, Puch X30 NG-2AH

Chain type: 415H · Manufacturer: GPO · Material: Steel · Color: black · Surface: powder-coated · Number of teeth: 45 pcs · Chain pitch: 1/2" x 3/16" · Ø inside: 94 mm · Number of fixing points: 6 pcs · Ø mounting hole: 6.7 mm · Thickness: 4.5 mm · Hole spacing 2: 68 mm · Ø bolt circle: 105.5 mm · Hole spacing: 36.5 mm · Cranking (offset): 8 mm

swiing® revival rear wheel spacer tube L=70 mm | Puch Maxi

Manufacturer: swiing® revival parts · Nominal diameter inside: 12 mm · Ø inside: 12.5 mm · Ø outside: 16 mm · Total length: 70 mm · Puch OEM number: 349.5.41.826.1

swiing® revival wheel axle LELEU & Grimeca wheel hub cast wheel rear | Puch

Manufacturer: swiing® revival parts · Material: Steel · Surface: galvanized (blue) · Thread type: MF12x1 (fine pitch thread) · Ø shaft: 11.9 mm · Ø outside: 11.8 mm · Width across flats: 19 mm · Total length: 185 mm · Shank length: 100 mm · Thread length: 26 mm · Thread length: 52.5 mm

SKF 6001 2RSH Ball bearing 12/28/8

Stock number: 6001 · Inner ring width: 8 mm · Manufacturer: SKF · Ball bearing closed: Yes · Dust protection type: 2RSH - NBR contact seal on both sides · Bearing clearance: CN (standard) · Bearing cage: Sheet steel cage ball-guided · Bearing type: Deep groove ball bearing · Ø inside: 12 mm · Ø outside: 28 mm · Width: 8 mm

Gurtner gasket carburetor float chamber AR | MBK, Motobécane

Manufacturer: Gurtner · Material: Sealing paper · Component group Carburetor: Sealing, revising · Thickness: 0.4 mm

Gurtner O-ring fuel connection carburetor AR1 | MBK, Motobécane (AV10)

Ø inside: 24 mm · Ø outside: 26 mm · Manufacturer: Gurtner · Material: Rubber · Color: black · Number of components: 1 pcs · Cord thickness: 1 mm · Place of use: Carburetor · Area of application: Original · Area of application: Standard
