Gurtner gasket inlet carburetor DG | Peugeot 103 SP, MVL

Gurtner carburetor D12G with air filter original | Peugeot 103 SP, MVL

Manufacturer: Gurtner · Component group Carburetor: Carburetor complete · Material: Aluminum · Material: Plastic · Nominal diameter: 12 mm · Ø Internal connection: 19 mm · Ø Inside entrance: 12 mm · Ø Output inside: 12 mm · Ø Air filter connection: 50 mm · Ø fuel hose connection: 6 mm · Choke control: Cable choke · Nozzle size: 66 · Mounting type: Plug connection clamped · Total length: 160 mm · Width: 110 mm · Height: 95 mm · Area of application: Original · Area of application: Standard

Gurtner carburetor D12G (243.0B) with air filter original | Peugeot 103 Vogue, 102

Manufacturer: Gurtner · Component group Carburetor: Carburetor complete · Material: Aluminum · Material: Plastic · Nominal diameter: 12 mm · Ø Internal connection: 19 mm · Ø Inside entrance: 12 mm · Ø Output inside: 12 mm · Ø Air filter connection: 50 mm · Ø fuel hose connection: 6 mm · Choke control: Cable choke · Nozzle size: 66 · Mounting type: Plug connection clamped · Total length: 115 mm · Width: 94 mm · Height: 87 mm · Area of application: Original · Area of application: Standard

Gurtner carburetor idle screw D12G

Component group Carburetor: Adjusting screws, float, etc. · Material: Steel · Surface: galvanized (blue) · Carburetor type: Gurtner DG · Total length: 21 mm · Thread type: M5x0.8 (standard thread)

Gurtner fuel filter carburetor AR2 / DG | Peugeot 102, 103, MBK, Motobécane

Manufacturer: Gurtner · Component group Carburetor: Adjusting screws, float, etc. · Material: Plastic · Color: white · Carburetor type: Gurtner AR · Carburetor type: Gurtner DG · Total length: 29 mm · Ø outside: 8 mm

Gurtner gasket float chamber carburetor DG | Peugeot 102, 103 Vogue, SP, MVL

Place of use: Carburetor · Ø inside: 22 mm · Ø outside: 27 mm · Cord thickness: 2 mm · Color: black · Manufacturer: Gurtner · Number of components: 1 pcs · Material: Rubber · Area of application: Original · Area of application: Standard

GPO fuel filter connection 6 mm aluminum silver (removable)

Material: Aluminum · Manufacturer: GPO · Surface: anodized · Ø outside: 22 mm · Ø outside: 28 mm · Filter type: Sintered metal · Total length: 38.7 mm · Total length: 77 mm · demountable: Yes · Color: silver · Ø inside: 4.5 mm · Ø fuel hose connection: 6.6 mm · Ø fuel hose connection: 7.6 mm

Petrol hose clamp (Ø 8 - 9.3 mm) Standard

Material: Spring steel · Outer width: 5.3 mm · Surface: galvanized (blue) · Color: silver · Ø outside: 9.5 mm · Ø inside: 7.5 mm · Mounting type: Plug connection clamped · Clamping range: 7.6 - 9.3 mm

GPO fuel filter connection 6 mm aluminum green (removable)

Manufacturer: GPO · Material: Aluminum · Surface: anodized · Color: green · Filter type: Sintered metal · demountable: Yes · Ø fuel hose connection: 6 mm · Total length: 77 mm · Ø outside: 28 mm

Lockable fuel filler cap | Piaggio Ciao

Material: Plastic · Color: black · Fuel filler cap: Plug 33 mm · Lockable: Yes · Vented: Yes · Ø External head: 54 mm · Height: 105 mm

Air filter Malossi replica | Piaggio Ciao, SI, Bravo, Boxer

Width: 98 mm · Height: 93 mm · Camouflaged: No · Material: Plastic · Area of application: Tuning · Color: black · Filter type: Foam · Ø outside: 52.5 mm · Mounting type: Plug connection clamped · Ø Internal connection: 50 mm

OMG fuel tap vertical M10x1 (for screwing in) pointing downwards

Manufacturer: OMG · Possible lever positions: open / closed / reserve · Material lever: Plastic · Filter type: Plastic net · Ø fuel hose connection: 6 mm · Installation direction: vertical / vertical · Outlet direction: below · Spare tube shape: straight · Reserve level: 50 mm · Thread type: MF10x1 (fine pitch thread) · Mounting type: screw in (thread)

Transval speedo drive 16" Peugeot 103 Vogue / SPX / RCX

Manufacturer: Transval · Material: Aluminum · Thread type: MF10x1 (fine pitch thread) · Overall width outside: 60 mm · Ø axle: 11 mm · Ø mounting hole: 11 mm · Place of use: right · Wheel size: 16 " · Total height: 58 mm · Ø outside: 41 mm · 4-edge speedometer cable: 2.6 mm

Speedometer cable 56 cm | Peugeot 103 MVL

Manufacturer: Made in Portugal · Color: black · Outer shell length: 560 mm · Thread type: MF10x1 (fine pitch thread) · Thread type: MF11x0.75 (fine pitch thread) · Total length: 585 mm · 4-edge speedometer cable: 1.8 mm

Engine gasket set | Peugeot 103

Manufacturer: Made in France · Number of components: 7 pcs · Area of application: Standard

Gurtner gasket float chamber carburetor DG | Peugeot 102, 103 Vogue, SP, MVL

Place of use: Carburetor · Ø inside: 22 mm · Ø outside: 27 mm · Cord thickness: 2 mm · Color: black · Manufacturer: Gurtner · Number of components: 1 pcs · Material: Rubber · Area of application: Original · Area of application: Standard
